STEERING- LOWER
86037580 GLIDE 01/03/07
5-46
8628
8410
PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86276970
70774
4
SCR, 3/8-16 X 3/4 HHCS SS NP
2 86258330
45011 1 UNIVERSAL
JOINT,
DOUBLE
3
86232800
27946
1
CHAIN, #40-1/2 PITCH X 36
4 86082310
62951 1 PLATE,
STEERING
5
86082840
66362
1
PLATE, CHAIN TENSIONER
6
86286410
70762
4
SCR, M10-1.5 X 35MM HHFS
7
86005810
57245
2
NUT, 1/4-20 HEX NYLOCK SS
8
86005860
57273
2
NUT, 1/4-20 X 12MM HEX BARREL
9
86270310
70760
2
EYEBOLT, 1/4-20 X 1.5 PLTD
10
86264490
73440
2
SPACER, .75OD X .39ID X .25 HDPE
11
86002850
27343
2
CHAIN, #40-1/2”P MASTER LINK
12
86278070
70761
1
SET SCREW, 1/4-20 X 3/4 SS
13
86094330
730116
1
STEERING ASM, LOWER SHAFT
14
86087260
730132
1
SPACER, 7/8 OD X .049W X 1.75L
15
86276780
70728
2
SCR, 5/16-18 X 3/4 HHCS SS
16 86228790 09111 1
BEARING, FLANGE .88OD X .75ID
X.75
17
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
18 86001030 09148 1
BEARING, BALL 3/4 BORE
SPHERED
19
86008610
80595
2
FLANGE, BEARING PRESS STEEL
20
86272900
67416
1
RING, 3/4” CLIP
21
86005610
57016
1
NUT, 7/8 DIA PUSHLOCK
