WHEELS & FRAME
86037580 GLIDE 11/05/08
5-54
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86238500 81427 3
GROMMET, 1.703ID X 2.5OD X .125
GRY
2 86092430 34385 1 FRAME, RIDER SCRUBBER
3 86232130 17309 2 CAP, 2.75 ID X 1.0 L BLK VINYL
4 86272910 67471 2 RING, 63/64 EXTERNAL SNAP
5A 86011090 89224 2
WHEEL ASM, 12 X 3.5 X 8
SCRUBBER COMPOUND
5B 86259890 89230 REF WHEEL ASM, 12 X 3.5 X 8 GRAY OPTION
6 86276920 70755 4 SCR, 3/8-16 X 1 HHCS SS NP
7 86010790 87163 4 WASHER, 3/8 SPLIT LOCK
8 86003450 29256 1 MOTOR ASM, 36V DRV. WHEEL
8A 86001460 140552 REF BRUSH SET, MOTOR SERVICE ONLY
8B 86215180 09142 REF BEARING, STEERING SERVICE ONLY
8C 86004760 47417 REF KIT, ARMATURE ASM FOR 29256 SERVICE ONLY
8D 86222190 54188 REF MOTOR & GEARBOX FOR 29256 SERVICE ONLY
8E 86217990 34403 REF
FRAME, STEERING MOUNT ASM
(29256)
SERVICE ONLY
8F 86217990 09143 REF BEARING, 60ID X 95OD SERVICE ONLY
9 86259880 89225 1
WHEEL, 12 X 4 X 8 SCRUB
COMPOUND
9A 86259900 89253 REF WHEEL, 12 X 4 X 8 GRAY OPTION
10 86277250 70818 8 SCR, M6 X 25MM HSNCS NP
11 86233410 81270 1 CLAMP, 3/4 DIA. CUSHION .406 DIA.
12 86008920 80889 2 BOOT, RUBBER TERM. ISOLATER
13 86087380 730419 2 SPACER, CLAMP *(5)
14 86274120 70096 4 SCR, 3/8-16 X 1.0 SHCS BLK
15 86173150 70946 2 SCR, 3/8-16 X 2.5 SHCS BLK
16 86317210 - 2 DOWEL, M8 X 25MM **
*SEE SERIAL NUMBER PAGE.
**CALL MANUFACTURER FOR SERIAL NUMBER.
