SCRUB DECK SIDE SQUEEGEE-36 IN
86037580 GLIDE 01/03/07
5-30
REF PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86005630
57022
2
NUT, 3/8-16 HEX NYLOCK THIN SS
2 86010890
89059 1 WHEEL,
BUMPER
3
86274010
70070
1
SCR, 3/8-16 X 2 HHCS
4
86005810
57245
9
NUT, 1/4-20 HEX NYLOCK SS
5
86087860
62944
1
STRAP, SECONDARY SQUEEGEE
6
86276780
70728
2
SCR, 5/16-08 X 3/4 HHCS SS
7
86007550
730154
1
SQUEEGEE BLADE, SECONDARY
8
86069580
140478
1
BRKT, SECONDARY SQUEEGEE
9
86276960
70773
9
SCR, 1/4-20 X 1 CARRIAGE SS
10
86083740
730094
1
PLATE, SQUEEGEE LEFT
11
86270830
57023
6
NUT, 5/16-18 HEX NYLOCK SS
12
86082220
62934
1
PLATE, RIGHT SQUEEGEE
13
86065960
05162
4
ARM, SKIRT LINKAGE
14
86277090
70786
3
SCR, 5/16-18 X 3 HHMS FL THD SS
15
86242120
48090
3
KNOB, 1.0 OD X 5/16-18
16
86005650
57031
3
NUT, 5/16-18 HEX
17
86226810
73245
3
SPRING, COMP .72 X 2.0 L X .067 W
18
86277120
70792
2
SCR, 5/16-18 X 1.00 PFHMS SS
19
86087890
730089
2
STRAP, SIDE SQUEEGEE
20
86007390
730093
2
SQUEEGEE, SIDE BLADE LINATEX
21
86083730
730092
1
PLATE, SQUEEGEE RIGHT
22
86259410
87206
8
WASHER, THRUST .51 ID X 1 OD X .063
23
86279380
87146
16
WASHER 1/2 ID X 1 D X .08 NYL
24
86010670
87029
10
WASHER, 5/16 FLAT SS
25
86271840
57285
2
NUT, 5/16-18 HEX NYLOCK THIN SS
26
86228840
09124
8
BEARING, FLANGED .314 D X .502 OD
27
86007020
70673
6
SCR, 5/16-18 X 1.25 HHCS SS
28
86082200
62932
1
PLATE, LEFT SQUEEGEE
29
86272580
80638
4
PIN, CLEVIS 3/8 X 1.25 PLTD
30
86272380
66217
4
PIN, CLEVIS 3/8 X 3/4 PLTD
31
86226830
73268
4
SPRING, EXT .68D X 3.00L X .098W
