SCRUB DECK LIFT-36 IN
86037580 GLIDE 11/05/08
5-32
REF PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86008720
80637
1
PIN, CLEVIS 3/8” X 2.375” PLTD
2
86014490
-
1
ACTUATOR, 36VDC 5.0 STRK SG36
*(3)
WAS 86000830
3
86277860
70787
2
SCR, 3/8-16 X 3.75 HHCS SS
4
86275960
70570
2
SCR, 5/16-18 X 2.5 CARRIAGE GR5
5
86091720
140579
2
BRKT, ACTUATOR LIFT SRS
6
86093970
730111
1
SCRUB DECK, 36” MIN
7
86270830
57023
3
NUT, 5/16-18 HEX NYLOCK SS
8
86270880
57032
2
NUT, 3/8-16 SERRATED FLG
9 86001320
140353 2 BALL
JOINT ASSY, 3/8-24 LH
10
86005830
57263
2
NUT, 3/8-24 UNF LH
11
86006440
67415
2
ROD, SCRUB LIFT
12
86005800
57217
2
NUT, 3/8-24 HEX JAM
13 86008810 80697 2 BALL
JOINT ASSY, 3/8-24 RH
14
86276920
70755
4
SCR, 3/8-16 X 1 HHCS SS NP
15
86008460
80102
6
SPACER, .500OD X .391ID X .400
16
86271530
57216
4
NUT, 3/8-24 HEX NYLOCK
17 86009050 81324 6 BEARING,
1/2ID X 11/32L NYLON
18
86005630
57022
8
NUT, 3/8-16 HEX NYLOCK THIN SS
19
86077330
31373
2
LINKAGE, .25 X 1.25 X 9.25
20 86066780
140500 1 BAR,
PANHARD
21 86009710 82312 1 VALVE,
36VDC
SOL 1/2” HOSEBARB
-
86003460
29260
-
DIAPHRAGM, SRVC PART SLND
SERVICE ONLY
-
86004620
47295
-
SOLENOID SPRING KIT
SERVICE ONLY
22
86276760
70728
1
SCR, 5-16-18 X 3/4 HHCS SS
23 86008550 80583 1 HORN,
36VDC
24
86005740
57112
2
NUT, 5/16-1/8 SERRATED FLANGE
25 86008740 80654 2 BUMPER,
ADJUSTMENT
26
86273780
70015
2
SCR, 1/4-20 X 3/4 HHCS SS NP
27
86005810
57245
2
NUT, 1/4-20 HEX NYLOCK SS
28
86008670
80606
1
COTTER, 3/8 RING
29 86255430 81311 2
SPRING, COMP 1.00 X 3.5 L X .135
W
30
86274010
70070
2
SCR, 3/8-16 X 2 HHCS
31
86254250
730163
2
SPACER, 1.0 OD X .391 ID X 1.13 L
32
86233150
20042
1
CLAMP, 3/8 HOSE
33
86282060
39563
1
HOSE, 1/2 ID NYLOBRAID X 21.5
34
86010730
87088
2
WASHER, 5/8 ID X 1.18 X .06 SS
*SEE SERIAL NUMBER PAGE.
