Squeegee –28 in & 36 in – Windsor Saber Glide 86037580 User Manual
Page 39
SQUEEGEE –28 IN & 36 IN
86037580 GLIDE 02/20/07
5-38
REF PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1
86082500
62979
1
PLATE, SQUEEGEE TOP 32 IN
2
86082510
62980
1
PLATE, SQG VERTICAL FILLER (F)
3
86082520
62981
1
PLATE, SQG VERTICAL FILLER (R)
4
86082530
62982
1
PLATE, SQUEEGEE BOTTOM 32 IN
5
86274130
70098
2
SCR, 8-32 X 3/8 PHTC ‘F’ PLTD
6 86009910
82576 1 VIAL,
LEVEL
7
86009200
81535
2
KNOB, 3/8-16 4 PRONG ALUM
8
86276870
70748
2
SCR, 3/8-16 X 2.50 CARRIAGE SS
9
86005630
57022
4
NUT, 3/8-16 HEX NYLOCK THIN SS
10
86010680
87030
2
WASHER, 3/8ID X 3/4OD NYLON
11
86008390
78493
1
TUBE ASM, SQUEEGEE VAC
12
86001850
14413
1
BAND, REAR SQUEEGEE
13
86007780
73576
2
SPRING, COMP .60D X 2.0L X .045W
14
86276990
70776
2
SCR, 3/8-16 X 3.5 CARRIAGE SS
15
86009170
81488
1
LATCH, SQUEEGEE STRAP
16
86009180
81489
1
STRIKER, SQUEEGEE STRAP REAR
17
86006400
67380
4
RIVET, 5/32 OF X 1/8 GRIP
18
86001860
14414
1
BAND, REAR SQUEEGEE
19
86005810
57290
2
NUT, 1/4-20 HEX NYLOCK THIN SS
20A
86001440
140533
1
BLADE, SQUEEGEE REAR LINATEX 1/4
20B
86229610
140585 REF
BLADE, SQUEEGEE REAR GUM 1/4
OPTION
20C
86001880
14416
REF
BLADE, SQUEEGEE REAR LINATEX 3/16
OPTION
20D
86229620
140597
REF
BLADE, SQUEEGEE REAR URETHANE
OPTION
21
86277000
70777
2
SCR, 1/4-20 X 1.5 CARRIAGE SS
22
86270830
57023
2
NUT, 5/16-18 HEX NYLOCK SS
23
86005840
57269
2
NUT, 3/8-16 HEX COUPLING SS
24
86276980
70775
2
SCR, 5/16-18 X 2 HHCS SS
25
86276920
70755
2
SCR, 3/8-16 X 1 HHCS SS NP
26
86005650
57031
2
NUT, 5/16-18 HEX
27
86010670
87029
2
WASHER, 5/16 FLAT SS
28 86001350
140390 4 BUSHING,
SPANNER .435 X 1.10
29
86011020
89202
4
WHEEL, 3” DIA CUSHION RUBBER
30
86069870
140531
2
BRACKET, SQG WHEEL
31
86006270
66276
2
PIN, CLEVIS 5/16 X 1.625 LG
32
86008660
80605
2
COTTER, 5/16” RING
33
86271820
57270
3
NUT, 5/16-18 CAPTIVE “J” PLTD
34
86007040
70680
3
SCR, 5/16-18 X 1 THUMB SS TYPE P
35A
86001490
140598
1
BLADE, SQUEEGEE FRONT (5-SLOTS)
35B
86001870
14415
REF
BLADE, SQUEEGEE FRONT (3-SLOTS)
OPTION
36
86001480
14412
1
BAND, SQUEEGEE FRONT
37
86004890
48095
2
KNOB, ALUM 3/8-16 NYLOCK NUT SS
NOTE: COMPLETE SQUEEGEE ASSEMBLY IS AVAILABLE, PN 47405.
