SCRUB DECK SIDE SQUEEGEE –32 IN
86037580 GLIDE 01/03/07 5-24
REF PART NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86094220 730106 1 SKIRT, RIGHT
2 86086840 730156 1 SCRUB DECK 32 SIDE SQUEEGEE
3 86226830 73268 4 SPRING, EXT .68D X 3.00L X .098W
4 86007020 70673 6 SCR, 5/16-18 X 1.25 HHCS SS
5 86010670 87029 10 WASHER, 5/16 FLAT SS
6 86094230 730107 1 SKIRT, LEFT
7 86005810 57245 13 NUT, 1/4-20 HEX NYLOCK SS
8 86007420 730100 2 SQUEEGEE, SIDE BLADE LINATEX
9 86276320 70633 9 SCR, 1/4-20 X1.0 CARRIAGE BZ
10 86087920 730102 2 STRAP, SIDE SQUEEGEE
11 86276900 70753 2 SCR, 5/16-18 X 1.25 PHFMS SS
12 86279380 87146 16 WASHER, 1/2” ID X 1” D X .08” NYL
13 86082170 62924 1 PLATE, LEFT DECK
14 86272580 80638 4 PIN, CLEVIS 3/8” X 1.25” PLTD
15 86228840 09124 8 BEARING, FLANGED .314 D X .502 OD
16 86270830 57023 8 NUT, 5/16-18 HEX NYLOCK SS
17 86065960 05162 4 ARM, SKIRT LINKAGE
18 86259410 87206 10 WASHER, THRUST .51 ID X 1 OD X .063
19 86005650 57031 2 NUT, 5/16-18 HEX
20 86226810 73245 2 SPRING, COMP .72D X 2.0L X .067W
21 86272380 66217 4 PIN, CLEVIS 3/8 X 3/4
22 86087960 730166 1 STRAP, 32 IN SIDE SQUEEGEE
23 86007580 730167 1 SQUEEGEE, 32 SIDE BLADE
24 86001480 140584 1 BRKT, 32 SIDE SQUEEGEE
25 86273780 70015 2 SCR, 1/4-20 X 3/4 HHCS SS NP
26 86276400 70642 1 SCR, 3/8-16 X 3 HHCS
27 86010890 89059 2 WHEEL, BUMPER
28 86005630 57022 1 NUT, 3/8-16 HEX NYLOCK THIN SS
29 86253960 730169 1 SKIRT, 32 IN SIDE DECK
30 86087970 730168 1 STRAP, 32 IN SIDE DECK
31 86276950 70772 2 SCR, 1/4-20 X 3/4 CARRIAGE SS
32 86277090 70786 2 SCR, 5/16-18 X 3 HHMS FL THD SS
33 86242120 48090 2 KNOB, 1.0 OD X 5/16-18
