Windsor Saber Glide 86037580 - Manual (Page 53)

VACUUM
86037580 GLIDE 01/03/07 5-52
REF
PART
NO.
PRV
NO.
QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86274800 70297 3 SCR, 1/4-20 X 1.5 HHMS
2 86069560 140476 1 BRACKET, VACUUM MOUNTING
3 86003010 27759 1 CUFF, HOSE 1.5” BLK A2161
4 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
5 86276780 70728 2 SCR, 5/16-18 X 3/4 HHCS SS
6 86005810 57245 6 NUT, 1/4-20 HEX NYLOCK SS
7 86005450 53799 1 VAC MOTOR ASM, 36VDC 3 STAGE
- 86230800 140550 1 BRUSH SET, VACUUM AMETEK SERVICE ONLY
- 86135310 140686 1
BRUSH SET, VAC 24V/36V
WINDSOR
SERVICE ONLY
8 86233140 20041 2 CLAMP, 2.0” WORM GEAR
9 86240170 39614 1 HOSE ASM, 1.5 BLK VAC X 19
10 86264920 27049 3 CABLE TIE, 7” UL/CSA
11 86091170 730174 1 TUBE, 2.0 OD X .05 W X 1.0 L
12 86233430 81431 1 CLAMP, 2.50 WORM GEAR
13 86064910 54194 1 MUFFLER, VAC MOTOR
