To install drum wraps, position the left

hand drum wrap over the left hand

drum, align with counterbalance cable;

slide groove in drum wrap towards the

left until tabs snap over drum in

between drum and ratchet gear. Repeat

for right hand side.
IMPORTANT: RIGhT aND lEFT haND

aRE alWays DETERMINED FROM INsIDE

ThE GaRaGE lOOkING OuT.

Drum wrap Installation

DRuM WRaP

(lEFT haND)

DRuM

(lEFT haND)

COuNTERbalaNCE

CablE

winding Springs Continued...

To wind the spring, rotate the winding shaft

clockwise, while watching the mark on the

winding shaft. Rotate the winding shaft to

the required number of turns for your door.

Then return to the right hand side and

wind the right hand spring to the required

number of turns. Place pawl knob in lower

position on both sides.

IMPORTANT: Mark number of spring

turns on TorqueMaster

Plus end bracket

warning tag(s).

NOTE: since total turns to balance door

can deviate from sPRING TuRN ChaRT

values by ± 1/2 turn, adjustments to the

recommended number of turns may be

required aFTER rear hangers assembly is

completed.

IMPORTANT!

hOlD ThE DOOR DOWN TO

PREVENT IT FROM RIsING uNExPECTEDly

IN ThE EVENT ThE sPRING Was

OVERWOuND aND

CauTIOusly REMOVE

VICE ClaMPs FROM VERTICal TRaCks.

IMPORTANT! aDjusTMENTs TO ThE

RECOMMENDED NuMbER OF TuRNs May

bE REquIRED. IF DOOR RaIsEs OFF ThE

FlOOR uNDER sPRING TENsION alONE,

ThEN REDuCE sPRING TENsION uNTIl

DOOR REsT ON ThE FlOOR. IF ThE DOOR

Is haRD TO RaIsE OR DRIFTs DOWN ON

ITs OWN, ThEN aDD sPRING TENsION.

Spring Turns

Door Height

Spring Turns

(6’ - 0”)

(6’ - 3”)

14 - 1/2

(6’ - 5”)

(6’ - 6”)

(6’ - 8”)

15 - 1/2

(6’ - 9”)

15 - 1/2

(7’ - 0”)

(7’ - 3”)

16 - 1/2

(7’ - 6”)

(7’ - 9”)

17 - 1/2

(8’ - 0”)

Number of Installed Spring Turns

lOCaTION FOR

MaRkING NuMbER

OF INsTallED

sPRING TuRNs

BACk Of TORqUEMASTER

PLUS END BRACkET wARNINg TAg(S)

GROOVE

IN DRuM

Tabs
