25
Tools Needed:
Tools Needed:
Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at www.wayne-dalton.com
INST
ALLA
TION
Place vice clamps onto both vertical
tracks just above the third roller. This is
to prevent the garage door from raising
while winding counterbalance springs.
FaIluRE TO PlaCE VICE ClaMPs
ONTO VERTICal TRaCk CaN
allOW DOOR TO RaIsE aND
CausE sEVERE OR FaTal
INjuRy.
Securing Door
for Spring winding
TRaCk
VICE ClaMPs
aTTaChED TO
TRaCk
Vice Clamps
wARNINg
22
PlaCE VICE
ClaMPs abOVE
3RD ROllER
starting on the right side, adjust the
cable drum assembly by rotating the
drum until the set screw faces directly
away from the header. loosen the set
screw no more than 1/2 turn.
Pull on the end of the cable to remove
all cable slack. Check to ensure the
cable is aligned and seated in the first
groove of the cable drum. snug the set
screw, and then tighten an additional
1-1/2 turns.
Cut off excess cable.
IMPORTANT: ENsuRE ThE CablE Is
alIGNED aND sEaTED IN ThE FIRsT
GROOVE OF ThE CablE DRuM PRIOR TO
WINDING sPRINGs.
NOTE: Illustrations show the right
TorqueMaster
® Plus drum, left
TorqueMaster ® Plus drum is
symmetrically opposite.
23
Cable Adjustment
Pliers/Wire
Cutters
Flat Tip
screwdriver
Cable Drum
No space between Ratchet
Pawl and Cable Drum
indicates engagement
Cable Drum
Ratchet Pawl
ENGAGED SIDE VIEW
No space between
Ratchet Pawl and
Cable Drum
ENGAGED UNDERNEATH VIEW
Space between Ratchet Pawl
and Cable Drum
non-indicates engagement
Cable Drum
Ratchet Pawl
DISENGAGED SIDE VIEW
No space between
Ratchet Pawl and
DISENGAGED UNDERNEATH VIEW
UPPER POSITION LOWER POSITION
LOWER POSITION SIDE VIEW UPPER POSITION SIDE VIEW
Ratchet Pawl in Lower Position Ratchet Pawl in Upper Position
Use these Illustration, in conjunction with the Instructions on the other side of
this label.
WARNING
Rachet Bracket is under
EXTREME SPRING
TENSION.
To avoid possible severe or
fatal injury, DO NOT remove
fasteners from ratchet bracket
until spring(s) are fully
wnwound.
To safely unwind spring(s)
read
and follow the directions in the
installation instructions/owners
manual.
DO NOT REMOVE THIS TAG.
sET sCREW
FIRsT GROOVE
Cable Drum
No space between Ratchet Pawl and Cable Drum
indicates engagement
Cable Drum
Ratchet Pawl
ENGAGED SIDE VIEW
No space between Ratchet Pawl and Cable Drum
ENGAGED UNDERNEATH VIEW
Space between Ratchet Pawl and Cable Drum
non-indicates engagement
Cable Drum
Ratchet Pawl
DISENGAGED SIDE VIEW
No space between Ratchet Pawl and
DISENGAGED UNDERNEATH VIEW
UPPER POSITION LOWER POSITION
LOWER POSITION SIDE VIEW UPPER POSITION SIDE VIEW
Ratchet Pawl in Lower Position Ratchet Pawl in Upper Position
Use these Illustration, in conjunction with the Instructions on the other side of
this label.
WARNING
Rachet Bracket is under
EXTREME SPRING
TENSION.
To avoid possible severe or
fatal injury, DO NOT remove
fasteners from ratchet bracket
until spring(s) are fully
wnwound.
To safely unwind spring(s)
read
and follow the directions in the
installation instructions/owners
manual.
DO NOT REMOVE THIS TAG.
sET sCREW
PlIERs
COuNTERbalaNCE CablE
IN FIRsT GROOVE
CaM PEak sTRaIT uP
COuNTERbalaNCE
CablE
NOTE: FOuR sECTION, 8’0” hIGh
DOOR Is shOWN.
