Tools Needed:
14
Tools Needed:
Please Do Not Return This Product To The Store. Contact your local Wayne-Dalton dealer.
To find your Wayne-Dalton dealer; refer to your local yellow pages / business listings or go to Find a dealer area online at www.wayne-dalton.com
Drums
IMPORTANT: RIGhT aND lEFT haND Is
alWays DETERMINED FROM INsIDE ThE
buIlDING lOOkING OuT.
NOTE: For door section identification see
page 4.
TorqueMaster ® counterbalance drums
are marked right and left hand. uncoil the
counterbalance cables and make sure you
place the right hand cable loop on the right
hand milford pin and place the left hand
cable loop on the left hand milford pin.
Insert a roller into bottom bracket of the
bottom section and insert another roller
at #1 end hinge at the top of the bottom
section. Repeat for other side.
NOTE: Verify astragal (bottom seal) is
aligned with door section. If there is more
than 1/2” excess astragal on either side,
trim astragal even with door section.
None
lEFT haND
TORquEMasTER ®
COuNTERbalaNCE
DRuM
bOTTOM
sECTION
MIlFORD PIN
#1 END hINGE
(hINGE TubE)
bOTTOM bRaCkET
bOTTOM
sECTION
asTRaGal
6
COuNTERbalaNCE
CablE ROllERs
bOTTOM
sECTION
NOTE: If you have fully adjustable jamb
brackets, skip this step and complete step
6.
Measure the length of the vertical tracks.
using the jamb bracket schedule, determine
the placement of the jamb brackets for your
door height and track type.
To install the jamb brackets, align the
twistlock tab on the quick install jamb
bracket with the quick install feature in the
track and turn the bracket perpendicular to
the track so the mounting flange is toward
the back (flat) leg of the track.
Installing q.I. Jamb Brackets
TOP
hOlE
bOTTOM
hOlE
MIDDlE
hOlE
3RD sET hOlEs
2ND sET hOlEs
1sT sET hOlEs
Tape Measure
5
quICk INsTall FEaTuRE
lEFT sIDE shOWN RIGhT sIDE shOWN
q.I. jaMb bRaCkET
TWIsTlOCk
Tab
JAMB BRACkET SChEDULE
DOOR
hEIghT
1ST SET 2ND SET 3RD SET
JAMB BkT POSITION JAMB BkT POSITION JAMB BkT POSITION
6’ 6” and 7’ 0”
3 (Section high Doors)
qIjb - 3 MIDDlE qIjb - 5 bOTTOM NOT aPPlICablE
8’ 0”
4 (Section high Doors)
qIjb - 3 MIDDlE qIjb - 6 TOP qIjb - 7 MIDDlE
