4
Function Tripp Lite Part
To Connect a PS/2 Computer to the KVM P774- Series PS/2 KVM Cable Kit
To Connect a USB Computer to the KVM P776- Series KVM Cable Kit
USB Adapter (connects a USB system to the P774
series KVM cable)
B015-000
Daisy-Chain Cables P772- Series Daisy-Chain Cables
2. System Requirements
2.1 Computer
2.2 Console
2.3 Cables
A VGA, SVGA or Multisync computer with a HD15 port. •
Note: On the B020-016, since the integrated LCD monitor’s maximum resolution is 1024 × 768, the computer’s resolution setting must not
exceed 1024 × 768. The B020-016-17 and B020-008-17 have a maximum resolution of 1280 x 1024, so the computer's resolution setting
must not exceed 1280 x 1024.
Either
a mini DIN 6 (PS/2) keyboard and mouse port 1.
a 5-pin DIN (AT-style) keyboard port (requires a P106-000 adapter) 2.
a USB Type A port 3.
A VGA, SVGA, or Multisync monitor capable of the highest resolution that you will be using on any •
system in the installation.
A PS/2 style mouse
•
A PS/2 style keyboard •
*Optional external console ports are included on the NetDirector Console KVM Switches.
This KVM switch requires the following custom-wired premium cables:
Note: 1. NetDirector KVM Switches do not support serial mice. Using a Serial-to-PS/2 adapter will not work.
2. If your computer has an AT-style keyboard socket, use a PS/2-to-AT keyboard adapter
(Tripp Lite #P106-000) to plug into the computer’s AT-style keyoard port.
