Tripp Lite B020-016-17 - Manual (Page 26)

26
9. Appendix A
9.1 Troubleshooting
9.2 Specifications
Symptom Possible Cause Action
Erratic behavior. Unit not receiving
enough power. Check that the Power Adapter supplied
with the unit is plugged in and functioning
properly.
Keyboard and/or Mouse not
responding on B022-016. Improper mouse and/or
keyboard reset. Unplug the cable(s) from the console
port(s), then plug it/them back in.
All Station IDs display as 01. Station 1 has lost power. Wait a few seconds for the system to
reinitialize the station sequence and
display the proper IDs
Function B020-008-17 B020-016 B020-016-17 B022-016
Max # of Direct CPU Connections 8 16
Max # of CPUs via Daisy-Chain 504 512
Port Selection Push-Buttons, OSD, Hotkeys OSD, Hotkeys
Online LEDs 8 (Orange) 16 (Orange)
Selected LEDs 8 (Green) 16 (Green)
Power LED Blue
Station ID N/A Orange
Console Connectors* HD15 F (Monitor), PS/2 F (Mouse), PS/2 F (Keyboard)
CPU Ports (8) HD15 F (16) HD15 F
Required Cable Kits (Sold Separately) P774-Series (PS/2), P776-Series (USB)
Firmware Upgrade Port (1) RJ11 F
Daisy-Chain Ports (1) DB25 M
(1) DB25 M, (1)
DB25 F
Daisy-Chain Cables P772-Series
Switches Firmware Upgrade Normal/Recovery Switch
AutoScan Interval User-Defineable via OSD (1-255secs.)
Keyboard and Mouse Emulation PS/2
Video
1280 x 1024,
DDC2 B
1024 x 768,
DDC2 B
1280 x 1024,
DDC2 B
1920 x 1440,
DDC2
Power
100-240V,
50/60Hz, 1A
120-240V,
50/60Hz, 24W
100-240V,
50/60Hz, 1A
AC Adapter:
Input 100-240V,
50/60Hz,
20-40VA, 0.8A
Output DC 9V,
1.2A
Operating Temperature 32° to 120° F
Storage Temperature -4° to 140° F
Humidity 0% to 80% RH
Housing Metal
Weight 30lbs 26.5lbs 30lbs 6.25lbs
Dimensions (H x W x D) in inches 1.75 x 17 x 24 1.75 x 17 x 20.4 1.75 x 17 x 24 1.75 x 17 x 6
*Console KVM Switches have optional external console ports
