2
Connecting Your Printer to a Network
18 PhaserShare Networking
Using the PhaserShare Administrator to configure Token Ring
1. In the PhaserShare Administrator Main window, select the desired
printer from the Printer List.
2. Click Configure Printer; this displays the Configure Printer dialog
box.
3. In the Configure Printer dialog box, click the Token Ring tab.
4. In the Token Ring tab, set the Token Ring parameters as desired.
5. Click OK.
6. You are prompted to reset the printer. Reset the printer to make the
changes take effect.
For more information on the PhaserShare Administrator, see the PhaserShare
Networking Manual on the printer’s CD-ROM.
Using PhaserLink software to configure Token Ring
For information on connecting to your printer via PhaserLink, see “Accessing
printer information from a browser” on page 69. For general information on
PhaserLink software, see Chapter 9, “PhaserLink Software: the Printer’s
Information Link”.
1. From the printer’s home page, click Configuration; this displays the
View and Configure Settings
page.
2. From the View and Configure Settings page, click View and
Configure Interface Settings
; this displays the View and Configure
Interface Settings page.
3. From the View and Configure Interface Settings page, click View and
Configure PhaserShare Settings (Token Ring card)
; this displays the
View and Configure PhaserShare Settings page for Token Ring.
4. Enter your settings into the fields for Token Ring Address, Speed, and
Bridging
. If you make an error, click Restore Initial Form Values and
start again.
5. When you are finished entering the settings, enter the Validation
Password
and click Do/Apply. If you are not sure of the password,
contact your system administrator.
6. Reset the printer to make the changes take effect.
