52
Specifications
AMPLIFIER SECTION
Continuous Average Power output (FTC)
Front Main L/R channels:
85 watts per channel min. RMS at 8 ohms, both channels driven from
20Hz to 20kHz with no more than 0.08% total harmonic distortion.
Center channel:
85 watts min. RMS at 8 ohms, driven from 20Hz to 20kHz with no
more than 0.08% total harmonic distortion.
Surround L/R channels:
85 watts per channel min. RMS at 8 ohms, both channels driven from
20Hz to 20kHz with no more than 0.08% total harmonic distortion.
Front Remote L/R channels:
85 watts per channel min. RMS at 8 ohms, both channels driven from 20Hz
to 20kHz with no more than 0.08% total harmonic distortion.
Continuous Power output (DIN)
Front Main L/R channels: 115W
×
2 at 6 ohms
Center channel: 115W at 6 ohms
Surround L/R channels: 115W
×
2 at 6 ohms
Front Remote L/R channels:115W
×
2 at 6 ohms
Maximum Power output (EIAJ)
Front Main L/R channels: 145W
×
2 at 6 ohms
Center channel: 145W at 6 ohms
Surround L/R channels: 145W
×
2 at 6 ohms
Front Remote L/R channels:145W
×
2 at 6 ohms
IM Distortion: 0.08% at rated power (FRONT)
Damping Factor: 60 at 8 ohms (FRONT)
Input Sensitivity/Impedance
PHONO : 2.5
µ
V, 50 kohms
LINE (CD, TAPE-1, 2, DVD,VIDEO-1, 2, 3) : 200
µ
V, 50 kohms
DIGITAL-2, 3 (COAXIAL) : 0.5 Vp-p, 75 ohms
Output Level and Impedance
Rec out (TAPE-1, 2,VIDEO-1, 2) : 200
µ
V, 2.2 kohms
Pre out (FRONT L/R,CENTER,SURROUND L/R) : 1 V, 560 ohms
(SUBWOOOFER) : 1 V, 2.2 kohms
Phono Overload: 120
µ
V RMS at 1,000 Hz, 0.5% THD.
Frequency Response: 20 to 30,000 Hz, +/-1 dB (STEREO)
RIAA Deviation: 20 to 20,000 Hz, +/-0.8 dB
Tone Control: BASS: +/-10 dB at 50 Hz
TREBLE: +/-10 dB at 10,000 Hz
Signal to Noise Ratio: PHONO: 80 dB (IHF A, 5
µ
V input)
CD/TAPE: 100 dB (IHF A)
VIDEO SECTION
Television Format: NTSC (U.S. and Canadian models)
NTSC/PAL (Other models)
Input Sensitivity/Impedance
DVD, VIDEO-1,2,3 (Composite):
1 Vp-p/75 ohms
S-VIDEO (Y signal):
1 Vp-p/75 ohms
S-VIDEO (C signal):
0.28 Vp-p/75 ohms
Output Level/Impedance
VIDEO (VIDEO-1,2,MONI) (Composite):
1 Vp-p/75 ohms
S-VIDEO (Y signal):
1 Vp-p/75 ohms
S-VIDEO (C signal):
0.28 Vp-p/75 ohms
TUNER SECTION
FM:
Tuning Range:
87.5 MHz to 108.0 MHz (50 kHz steps)
Usable Sensitivity: Mono: 11.2 dBf, 1.0
µ
V (75 ohms)
0.9
µ
V / 75 ohm DIN
Stereo: 17.2 dBf, 2.0
µ
V (75 ohms)
23
µ
V / 75 ohm DIN
50dB Quieting Sensitivity: Mono: 17.2 dBf, 2.0
µ
V (75 ohms)
Stereo: 37.2 dBf, 20
µ
V (75 ohms)
Capture Ratio: 1.5 dB
Image Rejection Ratio: U.S. & Canadian models: 40 dB
Other area models: 85 dB
IF Rejection Ratio: 90 dB
Signal-to-Noise Ratio: Mono: 76 dB
Stereo: 70 dB
Alternate Channel Attenuation: 55 dB, 50 dB (DIN)
AM Suppression Ratio:
50 dB
Total Harmonic Distortion: Mono: 0.15%
Stereo: 0.25%
Frequency Response: 30 - 15,000 Hz +/-1.0 dB
Stereo Separation: 45 dB at 1 kHz/30 dB at 100 - 10,000 Hz
Muting Level: 17.2 dBf, 2.0
µ
V (75 ohms)
AM:
Tuning Range:
European models
522 kHz - 1611 kHz (9 kHz steps)
U.S. & Canadian models
530 kHz - 1710 kHz (10 kHz steps)
Worldwide model
531 kHz - 1602 kHz (9 kHz steps)
530 kHz - 1710 kHz (10 kHz steps)
Usable Sensitivity: 30
µ
V
Image Rejection Ratio: 40 dB
IF Rejection Ratio: 40 dB
Signal-to-Noise Ratio: 40 dB
Total Harmonic Distortion: 0.7%
GENERAL
Power Supply: AC 120 V, 60 Hz
AC 230 V, 50 Hz
AC 120 and 220-230 V switchable, 50/60 Hz
Power Consumption: US and Canadian models: 4.8 A
Other area models:
460 W
Dimensions (W
×
H
×
D): 435
Ч
175
Ч
390 mm
17-1/8"
Ч
6-7/8"
Ч
15-3/8"
Weight: 12.0 kg (26.5 lbs) (AC 120 V, 60 Hz model)
12.9 kg (28.4 lbs) (Other models)
Specifications and features are subject to change without notice.
