12 Attention

277

12.5.4 When Using the IAR C Compiler (ICC)

12.5.4.1 Specify the Option

Please compile according to the following procedures and link.

At compilation
Specify the "-r" option.


Before linking
Open the linker's option definition file (extension .xcl) to be read when linking and add
"-FIEEE695" and "-y" options. The designation of "-y" option varies depending on the product.

Product Name

-y Option

The debugger for M32C

-ylmb

The debugger for M16C/R8C

-ylmb

The debugger for 740

-ylmba


At link
Specify the linker's option definition file name using "-f" option.

We do not evaluate other settings, so we can not recommend to append other options.

12.5.4.2 Command Execution Examples

The following shows examples of entering commands depending on the product

The debugger for M32C

>ICCMC80 -r file1.c
>ICCMC80 -r file2.c

>XLINK -o filename.695 -f lnkm80.xcl file1 file2


The debugger for M16C/R8C

>ICCM16C -r file1.c
>ICCM16C -r file2.c
>XLINK -o filename.695 -f lnkm16c.xcl file1 file2


The debugger for 740

>ICC740 -r file1.c
>ICC740 -r file2.c
>XLINK -o filename.695 -f lnk7400t.xcl file1 file2


The XCL file name varies depending on the product and memory model. For details, see the ICCxxxx
manual.
