7 Windows/Dialogs

179

Display format

Status

-

No change

CB

Operation code read (bytes)

RB

Operand read (bytes)

QC

Instruction queue buffer clea

r

CW

Operation code read (words)

RW

Operand read (words)


QN
Shows the number of bytes stored in the instruction queue buffer in the range 0 to 4.

B-T
Shows the level of the external break trigger (the EXTIN7 pin of the external trace signal input
cable). High level = "1", Low level = "0".

Q-T
Shows the level of the external trace trigger (the EXTIN6 pin of the external trace signal input
cable). High level = "1", Low level = "0".

76543210
Shows the status of the 8-bit external signal (pins EXTIN0 to EXTIN7 of the external trace signal
input cable). High level = "1", Low level = "0".

h" m' s: ms.us
Show the elapsed time from the target program beginning.
