7 Windows/Dialogs
197
•
The following are displayed in the Sematr area:
TA_TFIFO Task wait queue is in FIFO order
TA_TPRI Task wait queue is in task priority order
•
When a task connected to the SEM queue is in the state of waiting with timeout enabled (waiting
in twai_sem), a string "[tmo]", which indicates a state of waiting with timeout enabled, is
appended to a string displayed in the Semaphore Queue field.
When a task connected to the SEM queue is in the state of forced waiting (double waiting), a
string "[s]", which indicates double waiting, is appended to a string displayed in the Semaphore
Queue field.
Normal Display 26(_task26)
Display when in WAIT-SUSPEND 26(_task26)[s]
Display when in WAIT-SUSPEND with time out 26(_task26)[tmo][s]
•
Up to 8 characters can be displayed in the task name in the Semaphore Queue field.If a task
name exceeds 8 characters, the extra characters are omitted.
