7 Windows/Dialogs
203
7.14.9.2 Display the Cycle Handler Status(When the realtime OS is MRxx conformed to uITRON
specifications V.4.0.)
All the cycle handlers defined in the configuration are listed in the order of ID number. The function
of each item is listed below. (When the realtime OS is MRxx conformed to uITRON specifications
V.4.0.)
Item Contents
ID
ID No. of cycle handler
Name Name of cycle handler
Cycphs The activation phase (by the millisecond)
Cyctim The activation cycle time (by the millisecond)
Tmout The amount of time by the millisecond remaining before the cyclic
handler's next activation time
Status Activity status of cycle start handler
•
The following are displayed in the Status area:
TCYC_STA Cycle handler is in an operational state
TCYC_STP Cycle handler is in a non-operational state
