7 Windows/Dialogs
•
*2Display the Wait Cancellation Condition of Event Flag
Wfmode Status
TWF_ANDW
Waits for all bits set in the wait bit pattern to be set (AND wait)
TWF_ORW
Waits for any one bit set in the wait bit pattern to be set (OR wait)
7.14.3 Display the Ready Queue Status
In the MR window, select Popup Menu - [Mode] -> [Ready Queue].
The following data is displayed in the status bar.
7.14.3.1 Display the Ready Queue Status(When the realtime OS is MRxx conformed to uITRON
specifications V.3.0.)
The function of each item is as described below. (When the realtime OS is MRxx conformed to
uITRON specifications V.3.0.)
Item Contents
Pri Displays
priority
RdyQ
Shows the ID Nos. and task names of tasks in the ready queue
•
Up to 8 characters of the task name is displayed in the RdyQ field. When the task name exceeds 8
characters, the extra characters are omitted.
7.14.3.2 Display the Ready Queue Status(When the realtime OS is MRxx conformed to uITRON
specifications V.4.0.)
The function of each item is as described below. (When the realtime OS is MRxx conformed to
uITRON specifications V.4.0.)
Item Contents
Pri Displays
priority
Ready Queue
Shows the ID Nos. and task names of tasks in the ready queue
•
Up to 8 characters of the task name is displayed in the Ready Queue field. When the task name
exceeds 8 characters, the extra characters are omitted.
191
