7.14.7.2 Display the Mailbox Status (When the realtime OS is MRxx conformed to uITRON
specifications V.4.0.)
All the mail boxes defined in the configuration are listed in the order of ID number. The function of
each item is listed below. (When the realtime OS is MRxx conformed to uITRON specifications V.4.0.)
Item Contents
ID
ID No. of mailbox
Mbxatr
Attribute of each mailbox
Mailbox Queue (Wait)
ID No. and task name of tasks waiting for messages
Mailbox Queue (Message)
The messages stored in the mailbox
•
The following are displayed in the Mbxatr area:
TA_TFIFO
Task wait queue is in FIFO order
TA_TPRI
Task wait queue is in task priority order
TA_MFIFO
Message queue is in FIFO order
TA_MPRI
Message queue is in message priority order
•
When a task connected to the mail box queue is in the state of waiting with timeout enabled
(waiting in trcv_mbx), a string "[tmo]", which indicates the state of timeout enabled, is appended
to a string displayed in the Mailbox Queue (Wait) field.
When a task connected to the mail box queue is in the state of forced waiting (Double waiting), a
string "[s]", which indicates the state of double waiting, is appended to a string displayed in the
Mailbox Queue (Wait) field.
Normal Display
26(_task26)
Display when in WAIT-SUSPEND
26(_task26)[s]
Display when in WAIT-SUSPEND with time out
26(_task26)[tmo][s]
•
Up to 8 characters can be displayed in the task name in the Mailbox Queue (Wait) field. If a task
name exceeds 8 characters, the extra characters are omitted.
