42
Adding Various Effects to a Voice
Adding Modulation to the Sound (Rotary Effect)
Rotary is an effect which simulates the sound of rotating speakers. There is a choice of
two settings: Fast and Slow.
The Rotary effect can be applied to the following sounds.
• Voices assigned to buttons in the upper line of “Upper Organ” and “Lower Organ.”
• Voices assigned to the [Others] buttons for each part.
Some sounds do not allow the Rotary effect to be applied. For details refer to “Voice List” (p.
105).
fig.04-05
1.
Select the voice to which you wish to apply the Rotary effect.
2.
Press the Rotary Sound [On/Off] button (confirm that its indicator is
lit).
The Rotary effect will be applied to the voice.
3.
Press the Rotary Sound [Fast/Slow] button to switch between
Rotary Fast (LED lit) and Rotary Slow (LED turned off).
LED lit (Fast) The effect obtained is equivalent to speakers being rapidly ro-
tated.
LED turned off (Slow) Effect simulating the slow rotation of speakers.
When you switch the rotary effect from “Fast” to “Slow,” the modulation will slow
down gradually, and when you switch from “Slow” to “Fast” the modulation will speed
up gradually.
You can assign the Rotary Sound [Fast/Slow] button function to the foot switch located on the
left side of the Expression Pedal (p. 90).
On / Off
Rotary Sound
Fast/Slow
Piano Strings
Choir
Brass
Guitar
Full Jazz
Pipe
Lower
1
Lower
2
Pipe
Piano Strings
Choir
Brass
Guitar
Level Level Level Level
Organ Orchestral
Lower
Organ
Upper
Orchestral
