8632TXE and 8632TXM modules 43
Type Label Color/State Meaning
Green/Steady The port is operating at 100 Mb/s. 10/100
Off The port is operating at 10 Mb/s.
Green/Steady The port is connected, and the link
is good.
Green/Blinking Data is passing through this port.
Port
Link/Act
Off The port is disabled or has no link.
Green/Blinking The port is transmitting data.
Amber/Steady A fault condition exists on the line
or on the attached remote device.
TX
Off The port did not detect a fault
condition.
Green/Steady The port has a link and is enabled.
Green/Blinking The port is receiving data.
Amber/Steady The port has either no optical signal
or no link synchronization.
GBIC
RX
Off The port has a signal but no link.
The 8632TXE module supports up to 32 000 table entries in its forwarding
engine. For information about table entry characteristics, see Network
Design Guidelines (313197-E).
The 8632TXM module is an M module and supports up to 128 000 table
entries in its forwarding engine, allowing for large Layer 2 and Layer 3
configurations, including Internet routing tables. For information about table
entry characteristics, see Network Design Guidelines (313197-E).
The Metro Ethernet Routing Switch 8600 system has three hardware
operating modes:
• Default mode (32 000 table entries) supports up to 32 000 hardware
records. This mode supports all modules.
• M mode (128 000 table entries) supports up to 128 000 hardware
records. This mode supports M modules only.
• R mode supports up to:
— 256 000 IP routes
— 64 000 MAC entries
— 32 000 ARP entries
This mode supports R modules only.
