8692omSF module
131
To set up modem access, you need a DTE-to-DCE cable ( straight or
transmit cable) between the Modem port and a modem or terminal server.
"Pin assignments: DTE to DCE" (page 131)
describes the required cable
pin assignments.
Pin assignments: DTE to DCE
Switch
Modem
Signal
Pin number
DCE DB-9
pin number
DCE DB-25
pin number
RXD
2
2
3
TXD
3
3
2
DTR
4
4
20
GND
5
5
7
DSR
6
6
6
RTS
7
7
4
CTS
8
8
5
8692omSF module
Physical specifications
Height:
1.5 in. (3.8 cm)
Width:
15.4 in. (39.1 cm)
Depth:
18.5 in. (47.0 cm)
Weight:
7.2 lb (3.3 kg)
Electrical specifications
Input power:
90 W maximum
Thermal rating:
241 Btu/hr maximum
MTBF rating
355 643 hr
Nortel Metro Ethernet Routing Switch 8600
Installation — Modules
NN46220-306
02.02
Standard
4.2
7 July 2008
Copyright © 2005-2007, Nortel Networks
.
