Metro Ethernet Routing Switch 8600 modules interface characteristics
19
Maximum port densities for Metro Ethernet Routing Switch 8600 modules
Maximum number of ports per chassis
Module type
Port type
8003
8006
8010 and
8010co
1000BaseSX
16
32
64
1000BaseLX
16
32
64
1000BaseZX
16
32
64
1000BaseXD
16
32
64
1000BaseCWDM
16
32
64
8608GBE and
8608GBM
1000BaseT
16
32
64
8608GTE and
8608GTM
1000BaseT
16
32
64
8608SXE
1000BaseSX
16
32
64
8616GTE
1000BaseT
32
64
128
8616SXE
1000BaseSX
32
64
128
8624FXE
100BaseFX
48
96
192
1000BaseSX
Not
supported
120
240
1000BaseLX
Not
supported
120
240
1000BaseZX
Not
supported
120
240
1000BaseXD
Not
supported
120
240
1000BaseCWDM
Not
supported
120
240
8630GBR
1000BaseT
Not
supported
120
240
10BaseT/100BaseTX
64
128
256
1000BaseSX
4
8
16
1000BaseLX
4
8
16
1000BaseZX
4
8
16
1000BaseXD
4
8
16
1000BaseCWDM
4
8
16
8632TXE and
8632TXM
1000BaseT
4
8
16
8648GTR
10BaseT/100BaseTX/
1000BaseT
Not
supported
192
384
