46
TECHNICAL SPECIFICATIONS
Video Compatibility
SVGA, XGA, VGA
Video Quality Adjustment Automatic, for up to 1000 feet of CAT5 cable
Video Coupling DC
Video Connectors HD15 male to CPU
HD15 female to monitor
Maximum Input/Output Levels 1.45Vp-p (no offset)
Input / Output Impedance 75 ohms
Input Horizontal Frequency Range 15kHz to 130 kHz
Input Vertical Frequency Range 30 Hz to 150 Hz
Maximum Baud rate (HA-RS only) 115200 bps
Support RS232 Signals (HA-RS only) TXD,RXD,DSR,DTR,CTS,RTS
Terminal emulation (HA-RS only)
ASCII to VGA (800x600@60Hz, 80 characters wide x 30 lines high)- supports
VT100 emulation
User Keyboard/Mouse Connectors Female 6 pin miniDIN
Female USB Type A
CPU Keyboard/Mouse Connectors Male 6 pin miniDIN to device ports for PS/2 CPU
Male USB-Type A to device port for USB CPUs
Male 8 pin miniDIN to devices port for Legacy SUN CPU
Male RJ45 and USB Type A Male to console ports on serial devices
Mouse and Keyboard Compatibility Most PS/2 mice and keyboards
Most USB mice and keyboards
CPU Compatibility PS/2, Legacy SUN, USB SUN, USB MAC, Serially-Controlled servers/devices
Keyboard and Mouse Current Rating 500mA maximum
Sync Types Supported Separate and composite TTL Level
Mean Time Between Failures (MTBF) User Station: 72,786 hrs
Host Adapters: 316,996 hrs
Regulatory Approvals CE, RoHS
Interconnect Cable CAT 5/5e/6 Solid UTP/STP EIA/TIA 568 B wiring w/ male RJ45 connectors
Host Adapter Power Powered by CPU
User Station Power 5VDC/2.0A via 120V or 240V at 50 or 60Hz AC Adapter
Host Adapter Size (In.) WxDxH 3.1 x 3.7 x 1
User Station Size (In.) WxDxH 11 x 11 x 1.75
Distances and Resolutions for CAT5/CAT5e and CAT6 Cables
CABLE DISTANCE (feet) RESOLUTION
CAT5/CAT5e (UTP) 1000 1024x768 at 60Hz
CAT5/CAT5e (UTP) 700 1280x1024 at 60Hz
CAT5/CAT5e (UTP) 500 1600x1200 at 60Hz
CAT5/CAT5e (UTP) 400 1920x1440 at 60Hz
CAT5/CAT5e (STP) 600 800x600 at 60Hz
CAT5/CAT5e (STP) 500 1024x768 at 60Hz
CAT5/CAT5e (STP) 300 1280x1024 at 60Hz
CAT5/CAT5e (STP) 100 1920x1440 at 60Hz
CAT6 (UTP) 800 1024x768 at 60Hz
CAT6 (UTP) 600 1280x1024 at 60Hz
CAT6 (UTP) 500 1600x1200 at 60Hz
CAT6 (UTP) 350 1920x1440 at 60Hz
Note: Actual resolution may vary
depending upon the construction of the
CAT5 cable used.
