40
Network Configuration
This screen is only available in Matrix Mode (applicable when used with a PRIMUX Matrix Multi-User KVM Switch)- see
page 34 to change to Matrix Mode.
From the Administration Menu press <
N > to get to the Network Configuration Menu. (From Command Mode press < A > - < N >.)
To enable the PRIMUX Matrix to be accessible via Telnet, the IP Address, Gateway, and DNS settings must first be configured.
Figure 40- Network Configuration page
Function Description Keystroke
IP Mode Toggle, using the between “Static” or “DHCP”.
- In “Static” mode, the user must fill in all appropriate IP settings.
- In “DHCP” mode, the DHCP server will fill all IP settings in
automatically.
M-Spacebar
IP Address Open a field to enter an appropriate IP address (default is 192.168.1.22) I
Subnet Mask Open a field to enter an appropriate subnet mask S
Gateway Open a field to enter an appropriate gateway G
Preferred DNS Open a field to enter a preferred DNS address P
Alternate DNS Open a field to enter an alternate DNS address A
Telnet Toggle telnet access between enabled and disabled T- Spacebar
Help Open topic specific help page F1
---- Exit and return to the Administration Menu Esc
