Wireless ADSL2+ Modem Router DG834G User Manual
B-2 NETGEAR VPN Configuration
v1.0, May 2008
Step-By-Step Configuration
1. Configure the DG834G v5 as in the gateway-to-gateway procedures using the VPN Wizard
(see “Setting Up a Gateway-to-Gateway VPN Configuration” on page 6-18 ), being certain to
use appropriate network addresses for the environment.
The LAN addresses used in this example are as follows:
a. Enter toFVL328 for the connection name.
b. Enter 22.23.24.25 for the remote WAN’s IP address.
c. Enter the following:
• IP Address: 172.23.9.1
• Subnet Mask: 255.255.255.0
Figure B-1
Note: Product updates are available on the NETGEAR website at
http://www.netgear.com.
Unit WAN IP LAN IP LAN Subnet Mask
DG834G 14.15.16.17 10.5.6.1 255.255.255.0
FVL328 22.13.24.25 172.23.9.1 255.255.255.0
