Wireless ADSL2+ Modem Router DG834G User Manual

Virtual Private Networking

6-23

v1.0, May 2008

6. Click Done on the Summary screen (see

procedure. The VPN Policies screen displays, showing that the new tunnel is enabled.

7. Repeat these steps for the DG834Gv5 on LAN B, and pay special attention to using the

following network settings:

•

WAN IP of the remote VPN gateway (for example, 14.15.16.17)

•

LAN IP settings of the remote VPN gateway:

–

IP Address (for example, 192.168.0.1)

–

Subnet Mask (for example, 255.255.255.0)

–

Preshared Key (for example, 12345678)

8. Use the VPN Status screen to activate the VPN tunnel by performing the following steps:

Figure 6-26

Note: See

for

information about how to enable the IKE keepalive capability on an existing
VPN tunnel.

Note: The VPN Status screen is only one of three ways to active a VPN tunnel. See

for information about the other ways.
