Wireless ADSL2+ Modem Router DG834G User Manual
Virtual Private Networking 6-17
v1.0, May 2008
To launch this function, click the Windows Start button, then select Programs > NETGEAR
ProSafe VPN Client > Log Viewer. The Log Viewer screen for a successful connection is
shown in the following figure:
9. The Connection Monitor screen for this connection is shown in the following figure:
In this example you can see these settings:
• The DG834Gv5 has a GW Address (public IP WAN address) of 22.23.24.25.
• The DG834Gv5 has a Remote Address (LAN IP address) of 192.168.3.1.
• The VPN client PC has a Local Address (dynamically assigned address) of 192.168.2.2.
Figure 6-17
Note: Use the active VPN tunnel information and pings to determine whether a failed
connection is due to the VPN tunnel or some reason outside the VPN tunnel.
Figure 6-18
