Wireless ADSL2+ Modem Router DG834G User Manual
6-40 Virtual Private Networking
v1.0, May 2008
4. Enter these policy settings:
5. Click Apply. The VPN Policies screen displays:
Auto Policy Field Setting
General Policy Name GtoG
Remote VPN Endpoint
Address Type Fixed
Remote VPN Endpoint
Address Data 22.23.24.25
Local LAN Use the default settings.
Remote LAN IP Address Select Subnet address from the drop-down list.
Start IP Address 192.168.3.1
Subnet Mask 255.255.255.0
IKE Direction Initiator and Responder
Exchange Mode Main Mode
Diffie-Hellman (DH) Group Group 2 (1024 Bit)
Local Identity Type Use the default setting.
Remote Identity Type Use the default setting.
Parameters Encryption Algorithm 3DES
Authentication Algorithm MD5
Pre-shared Key 12345678
Figure 6-44
