Wireless ADSL2+ Modem Router DG834G User Manual
Virtual Private Networking 6-7
v1.0, May 2008
To configure a client-to-gateway VPN tunnel using the VPN Wizard, follow this procedure:
1. Log in to the modem router at its LAN address of http://192.168.0.1 with its default user name
of admin and password of password. On the main menu, select VPN Wizard. The VPN
Wizard screen displays:
2. Click Next to proceed. Fill in the Connection Name and the pre-shared key fields. Select the
radio button for the type of target end point, and then click Next to proceed.
VPN Endpoint Local IPSec ID LAN IP Address Subnet Mask
FQDN or Gateway IP
(WAN IP Address)
Client toDG834 — — Dynamic
DG834Gv5 toClient 192.168.3.1 255.255.255.0 22.23.24.25
Figure 6-4
Figure 6-5
Table 6-3. VPN Tunnel Configuration Worksheet (continued)
Enter the new connection name,
for example, 12345678.
Enter the pre-shared key.
Select the radio button:
A remote VPN client (single PC).
