12 • UDP
T1/E1 DACS Administrators’ Reference Guide
80
Introduction
Introduction
User Datagram Protocol (UDP) is supported by the DACS. Detailed information regarding the SNMP man-
agement information base (MIB) variables can be found in RFC1213: Management Information Base for
Network Management of TCP/IP-based internets: MIB-II.
To manage and collect statistics on UDP, click on
UDP
under the
Configuration Menu
to display the
UDP
win-
Figure 30. UDP window
Handling of NETBIOS UDP Broadcasts (boxNetbiosUdpBridging)
Enables the passing of broadcast UDP packets with a port of 137 and 138 from other interfaces to the local
LAN interface. Netbios uses these packets to communicate with WINS servers. A WINS server can work with-
out this option enabled, but the remote PC will appear to be on the LAN. The following options are available:
•
doNotPassNetbiosBroadcasts(0)
•
passNetbiosBroadcasts(1)
Received (udpInDatagrams)
The total number of UDP datagrams delivered to UDP users.
Received With No Ports (udpNoPorts)
The total number of received UDP datagrams for which there was no application at the destination port.
Others Received with No Delivery (udpInErrors)
The number of received UDP datagrams that could not be delivered for reasons other than the lack of an
application at the destination port.
Sent (udpOutDatagrams)
The total number of UDP datagrams sent from this entity.
