96
RQT9431
Channel Settings
freesat Channel List
You can set channel list of freesat.
1 Press
[e, r] to select “freesat Channel List”, then press [OK].
RETURN
freesat Channel List
115 ITV3
116 ITV3+1
Hide
117 ITV4
118 ITV4+1
120 Channel 4
121 Channel 4+1
122 E4
Page UP
Page Down CH
Select
2 Press [e, r] to select the channel.
To hide unwanted channels
Press [OK]. The check mark disappears.
You cannot select it by pressing [1, 2 CH].
(But you can select it by pressing the numbered buttons to enter
the channel number directly.)
Press [OK] again to reveal.
freesat Auto Setup
You can restart auto setting for freesat channels if the setup
(
➔ 13) fails for some reason.
However, if you perform “freesat Auto Setup”, all channel settings
are deleted. Confirm the programme you set the timer recording
after freesat Auto Setup. Please reset it if the setting information is
not correct. Recordings on the HDD are not be deleted.
1 Press
[e, r] to select “freesat Auto Setup”, then press [OK].
When the confirmation screen appears
2 Press [w] to select “Yes”, then press [OK].
Tips
You can also use the following method to restart freesat
Auto Setup. When the unit is turned on and stopped,
press and hold [1 CH] and [CH 2] on the main unit
simultaneously for about 5 seconds.
freesat Auto Setup screen appears.
•
–
Other Satellite Channel List
You can set channel list of other satellite services.
1 Press
[e, r] to select “Other Satellite Channel List”, then press
[OK].
2 Press [e, r] to select the channel.
Press the “Red” button to delete the channel.
Press the “Green” button to swap the channel. And, press the
numbered buttons to enter the channel number you want to
swap, then press [OK].
Press the “Yellow” button to sort channels.
Press the “Blue” button to profile the channel.
To hide unwanted channels
Press [OK]. The check mark disappears.
You cannot select it by pressing [1, 2 CH].
(But you can select it by pressing the numbered buttons to enter
the channel number directly.)
Press [OK] again to reveal.
•
•
•
•
Other Satellite Tuning Menu
You can tune channels from other satellites.
Press [OK] to show the following settings.
RETURN
Other Satellite Tuning Menu
Auto Setup
Manual Tuning
OK
Access
Dish Setup
•
Auto Setup
You can start the auto setup of the other satellite services.
(
➔ 16, Tuning in Other Satellite Services)
RETURN
Other Satellite Auto Setup - Satellite Selection
freesat and other satellite channels
Satellite Selection
Search Mode
Start
Select
Change
Astra2/Eurobird
All
Channel Type All
Manual Tuning
You can set the channel of the other satellite manually.
RETURN
Other Satellite Manual Tuning
Transpounder Frequency
Polarisation
Start Scan
Se ect
Horizontal
10773
Symbol Rate (Ksym/s) Auto
0 - Enter Frequency 9
1 Press [e, r] to select “Transpounder Frequency”
2 Press the numbered buttons to enter the transpounder
frequency.
3 Press [e, r] to select “Polarisation”.
4 Press [w , q] to select “Horizontal” or “Vertical”.
5 Press [e, r] to select “Symbol Rate (Ksym/s)”.
6 Press [w , q] to select the desired symbol rate, then press
[OK].
–The scan starts.
Dish Setup
You can set the dish setup manually.
RETURN
EXIT
Dish Setup
Satellite services may not be available if changed!
LNB Low Band Frequency (MHz)
LNB High Band Frequency (MHz)
Select
10600
9750
22KHz Command On
0 - Enter Frequency 9
Reset all
1 Press [e, r] to select “LNB Low Band Frequency (MHz)”.
2 Press the numbered buttons to enter the LNB Low Band
frequency.
3 Press [e, r] to select “LNB High Band Frequency (MHz)”.
4 Press the numbered buttons to enter LNB High Band
frequency.
5 Press [e, r] to select “22KHz Command”.
6 Press [w , q] to select “On” or “Off”.
Press the “Red” button to reset all settings. •
Signal Condition
You can check the quality and strength of digital satellite broadcast
signals. Realign the dish if you are receiving a poor signal.
1 Press
[e, r] to select “Signal Condition”, then press [OK].
2 Press [w , q] to select the input you want to check.
RETURN
Satellite Signal Condition
Dish Input
Channel Name
Change Input
Input 1
101 BBC 1 Wales
Network ID 003B
Transport Stream ID 07FF
Satellite Lock Indicator Not Locked
Channel UP
Channel Down
Signal Quality
Signal Strength 0 10
0 10
1
2
CH
The quality and strength of the signal are shown. Press [1, 2 CH]
to select the channel.
Signal Quality
Below 2 (display red) The signal quality is so poor that there may
be interference in the pictures and sound.
2–5 (display orange) The signal quality is basically adequate, but
brief interference in the pictures and sound
is possible in isolated case.
Over 5 (display green) Optimum picture and sound quality.
