Panasonic LC2H - Manual (Page 32)

PM4S
E43149 5A250VAC
PILOT DUTY C300 E43149
(C-UL) 5A250VAC
PILOT DUTY C300
— —
QM4H
E43149 5A250VAC
PILOT DUTY C300 E43149
(C-UL) 5A250VAC
PILOT DUTY C300
— —
FOREIGN SPECIFICATIONS
TIMER
Accessories
Products
Name
Recognized by UL Standards Certified by CSA Standards Lloyd’s Register Standards
Remarks
File No. Recognized rating File No. Certified rating File No. Certified rating
PM4H-A
PM4H-S
PM4H-M
PM4H-SD
PM4H-W E122222 5A250VAC
PILOT DUTY C300 LR39291 5A250VAC
PILOT DUTY C300
98/10004
5A 250V AC
(resistive)
PM5S-A
PM5S-S
PM5S-M E59504
(C-UL) 5A250VAC
PILOT DUTY C300 E59504
(C-UL) 5A250VAC
PILOT DUTY C300
— —
PM4H-F
E122222 3A250VAC
PILOT DUTY C300 LR39291 3A250VAC
PILOT DUTY C300
98/10004
3A 250V AC
(resistive)
LT4H
LT4H-L
LT4H-W
E122222
5A250VAC
PILOT DUTY C300
E122222
(C-UL)
5A250VAC
PILOT DUTY C300
— —
100mA30VDC 100mA30VDC
PMH
E59504 7A1/6HP125VAC
7A1/6HP250VAC
3A30VDC
PILOT DUTY C300 LR39291 7A1/6HP125VAC
7A1/6HP250VAC
3A30VDC
PILOT DUTY C300 88/10123 125V3.5A (COS φ
]
0.4)
250V2A (COS φ]0.4)
250V7A(COS φ]1.0)
“The standard models conform to
the UL/CSA standard.
(To place an order, you do not
need to specify the tailing charac-
ter
□
9 of each item number.)”
The standard models conform to
the LLOYD standard.
MHP
MHP-M E59504 5A250VAC LR39291 5A250VAC 88/10123 250V5A (COS φ]1.0) “The standard models conform to
the UL/CSA standard.
(To place an order, you do not
need to specify the tailing charac-
ter
□
9 of each item number.)”
S1DX
(Relay
output)
2C
E122222 7A125VAC
6A250VAC
1/6HP125, 250VAC
PILOT DUTY C300 LR39291 7A125VAC
6A250VAC
1/6HP125, 250VAC
PILOT DUTY C300
98/10004
7A 250V AC
(resistive)
4C
E122222 5A250VAC
1/10HP125, 250VAC
PILOT DUTY C300 LR39291 5A250VAC
1/10HP125, 250VAC
PILOT DUTY C300
98/10004
5A 250V AC
(resistive)
Products Name
Recognized by UL Standards Certified by CSA Standards Lloyd’s Register Standards
Remarks
File No. Recognized rating File No. Certified rating File No. Certified rating
Common mount-
ing tracks for
timers
E59504 10A250VAC
AT8-RFD (AT78039)
7A250VAC
AT8-DF8L (ATA48211)
8P cap was an approved
as an option.
AD8-RC (AD8013) LR39291 10A250VAC
AT8-RFD (AT78039)
7A250VAC
AT8-DF8L (ATA48211)
8P cap was an approved
as an option.
AD8-RC (AD8013)
— —
E148103 AT8-DF8K (ATC180031)
AT8-DF11K (ATC180041)
AT8-R8K (AT78041)
AT8- R11K (AT78051) E148103
(C-UL) AT8-DF8K (ATC180031)
AT8-DF11K (ATC180041)
AT8-R8K (AT78041)
AT8- R11K (AT78051)
— —
S1DXM-
A/M
(Relay
output) 2C
E122222 7A125VAC
6A250VAC
1/6HP125, 250VAC
PILOT DUTY C300 LR39291 7A125VAC
6A250VAC
1/6HP125, 250VAC
PILOT DUTY C300
98/10004
7A 250V AC
(resistive)
4C
E122222 5A250VAC
1/10HP125, 250VAC
PILOT DUTY C300 LR39291 5A250VAC
1/10HP125, 250VAC
PILOT DUTY C300
98/10004
5A 250V AC
(resistive)
