LC2H
2) Installation frame type
1 Standard type
Note) Please ask us about types without front resetting.
2 Backlight type
2. PC board mounting type
Specifications
No. digits Counting speed Front reset Input method Part No.
8 digits
2 kHz/30 Hz switchable
Yes
Non-voltage input type LC2H-F-2KK
Voltage input type (4.5 to 30 V DC) LC2H-F-DL-2KK
30 Hz Free voltage input type (24 to 240 V AC/DC) LC2H-F-FV-30
No. digits Counting speed Front reset Input method Part No.
8 digits 2 kHz/30 Hz switchable Yes Voltage input type (4.5 to 30 V DC) LC2H-F-DL-2KK-B
No. digits Counting speed Front reset Input method Part No.
8 digits
2 kHz
No Non-voltage input type
LC2H-C-2K-N
30 Hz LC2H-C-30-N
1. Panel mounting type
Notes) 1. The value given for battery life is calculated based on continuous operation (count input signal ON/OFF = 1:1), therefore, this value is not guaranteed.
Also, battery life is decreased 30% when operation is continuous with 2 kHz count inputting in 2 kHz mode.
2. Operation is at 25 Hz when using 24 V AC.
3. Only for installation frame type.
Type
Item
Standard type Backlight type Standard type
Non-voltage input Voltage input Free voltage type
No. digits 8 digits
External power supply Not required (built-in battery)
Max. counting speed 2 kHz/30 Hz (Switchable by switch) 30 Hz (Note 2)
Count
input
Min. input signal width
(ON: OFF = 1:1)
0.25 ms/16.7 ms (Switchable by switch) 16.7 ms
Input method (signal)
Non-voltage input using
contacts or open collector
connection
High level: 4.5 to 30 V DC
Low level: 0 to 2 V DC
High level:
24 to 240 V AC/DC
Low level:
0 to 2.4 V AC/DC
Input impedance
When shorted:
Max. 10 k Ω
When open:
Max. 750 k Ω
Approx. 4.7 k Ω —
Residual voltage Max. 0.5 V — —
Reset
input
Min. input signal width 200 ms
Input method (signal)
Non-voltage input using
contacts or open collector
connection
High level: 4.5 to 30 V DC
Low level: 0 to 2 V DC
Non-voltage input using
contacts or open collector
connection
Input impedance
When shorted:
Max. 10 k Ω
When open:
Max. 750 k Ω
Appox. 4.7 k Ω
When shorted:
Max. 10 k Ω
When open:
Max. 750 k Ω
Residual voltage Max 0.5 V — Max. 0.5 V
Display method 7-segment LCD
7-segment LCD
With green/red backlight
7-segment LCD
Breakdown voltage (initial) Between charged and uncharged parts: 1,000 V AC for 1 minute.
Between charged and
uncharged parts: 2,000 V
AC for 1 minute.
Insulation resistance (initial) Min. 100 M Ω (measured at 500 V DC) Measurement location same as for break down voltage.
Backlight power — 24 V DC (±10%) —
Protective construction (Note 3) IEC Standard IP66 (only panel front: when using rubber gasket)
Accessories (Note 3) Rubber gasket, mounting bracket
Battery life 7 years (at 25°C 77°F ) Note 1 6 years (at 25°C 77°F )
