Accessories
• Panel cover (Black)
LC4H Panel cover (4 digits)
AEL58011 AEL58012 AEL58013
The black panel cover is also available so that you can change the appearance of the panel by changing the panel cover.
The color of the standard panel cover is ash gray.
LC4H Panel cover (6 digits) LC4H-S Panel cover (4 digits)
Mounting parts
• Rubber gasket
• Mounting rails (Applicable for
DIN and IEC standards)
• Mounting frame
• Fastening plate
ATC18002
AT8-DLA1
Length: 1 m
aluminum
Applicable for LC4H
series
Applicable for LC4H
series
For holding DIN rails
The rubber gasket is enclosed in the LC4H
series.
AT8-DA4
ATA4806
50.0
1.969
50.0
1.969
1.0
.039
48
1.890
48 1.890
68 2.677
Oval hole, 40-5.5 Ч15 40-.217 Ч.591
10
.217
5.5
15 5
27
1.063
24 35
.945 1.378
7.5
.295
1.5
.059
15
2.75R .108R
1,000
15
±1 39.37 ±.039
15
.591 .591 .591 .394 .394 .197 .197 .591
10 5
ATA4806
UP
12
.472
50
1.969
M4
M.157
10
10
.394
.394
DOWN
UP
LOCK
RESET
LC4H
COUNTER
LOCK
RESET
COUNTER
LC4H DOWN
UP
RESET
LC4H
COUNTER
SET/LOCK
AEL58014
LC4H-S Panel cover (6 digits)
RESET
COUNTER
LC4H
SET/LOCK
AEL68011
LC4H-W Panel cover
COUNTER
SET/LOCK
RESET
LC4H-W
DIN SIZE COUNTERS COMMON OPTIONS
• Protective cover for DIN 48 size
AQM4803
Flexible type
50
1.969
50
1.969
11
.433
