83
2.6.3.2.Displaying the Current STA for Ports
The parameters shown in the following figure and table are for port STA Information.
Bridge Menu: Spanning Tree Port Information (Port
1-12)
===========
Port Type Status Designated Designated
Designated
Cost Bridge
Port
-----------------------------------------------------------------
--------
1 100TX DISABLED 0 32768.00E800340000
128.1
2 100TX DISABLED 0 32768.00E800340000
128.2
3 100TX DISABLED 0 32768.00E800340000
128.3
4 100TX DISABLED 0 32768.00E800340000
128.4
5 100TX DISABLED 0 32768.00E800340000
128.5
6 100TX DISABLED 0 32768.00E800340000
128.6
7 100TX DISABLED 0 32768.00E800340000
128.7
8 100TX DISABLED 0 32768.00E800340000
128.8
9 100TX DISABLED 0 32768.00E800340000
128.9
10 100TX DISABLED 0 32768.00E800340000
128.10
11 100TX DISABLED 0 32768.00E800340000
128.11
12 100TX DISABLED 0 32768.00E800340000
128.12
Page>
Return to previous panel.
Use or arrow keys to move. to select.
Parameter Description
