148
chapter 3.)
Parameter Default Description
IGMP
Router
Timeout
5 A switch port that stops receiving multicast protocol packets for
this interval will be removed from the IGMP forwarding list.
Range: 3 - 5 minutes
IGMP
Group
Timeout 5 The time between last spotting an IGMP Report message for an
IP multicast address on a specific port and the switch removing
that entry from its list.
Range: 3 - 5 minutes
3.6.6.3.Static ARP Configuration
Use the following screen to display or edit entries in the Static ARP Table. Entries added
to this table are retained until the associated IP interface is deleted or the switch is reset
to the factory defaults.
Parameter Description
IP Address IP address statically mapped to a physical MAC address.
MAC Address MAC address statically mapped to the corresponding IP address.
Interface The index number of the IP interface that will use this static ARP entry.
See chapter 3 “Subnet Configuration” or chapter 3 “Displaying Subnet
Information”.
Note:
To add a static address, specify it in the dialog box at the bottom of the screen,
and press Add. To delete a static address, click on the edit icon ( ) for the
required entry, and then press Delete.
