Bridge Menu: Spanning Tree Bridge Information
===========
Priority : 32768
Hello Time (in seconds) : 2
Max Age (in seconds) : 20
Forward Delay (in seconds) : 15
Hold Time (in seconds) : 1
Designated Root : 32768.00E800340000
Root Cost : 0
Root Port : 0
Configuration Changes : 0
Topology Up Time : 847850 (0 day 2 hr 21 min 18
sec)
Return to previous panel.
Use to select.
Parameter Description
Priority
Device priority is used in selecting the root device, root port, and
designated port. The device with the highest priority becomes the STA
root device. However, if all devices have the same priority, the device
with the lowest MAC address will then become the root device.
Hello Time The time interval (in seconds) at which the root device transmits a
configuration message.
Max Age The maximum time (in seconds) a device can wait without receiving a
configuration message before attempting to reconfigure.
Forward Delay The maximum time (in seconds) the root device will wait before
changing states (i.e., listening to learning to forwarding).
Hold Time The minimum interval between the transmission of consecutive
Configuration BPDUs.
Designated
Root The priority and MAC address of the device in the Spanning Tree that
this switch has accepted as the root device.
Root Cost The path cost from the root port on this switch to the root device.
Root Port The number of the port on this switch that is closest to the root. This
switch communicates with the root device through this port. If there is
no root port, then this switch has been accepted as the root device of
the Spanning Tree network.
Configuration
Changes The number of times the Spanning Tree has been reconfigured.
Topology Up
Time The time since the Spanning Tree was last reconfigured.
