physically adjacent neighbors.
OSPF Virtual Neighbor Table
===========================
Area ID Router ID IP Address Option State
Events
Page 1
The page number.
| READ/WRITE
Use
Parameter
Description
Area ID
The transit area the virtual link must cross to connect the border routers.
Router ID
The OSPF identifier for the router at the other end of the link.
IP Address
IP address of the border router at the other end of the link.
Option
The optional OSPF capabilities supported by the neighbor. The
neighbor's optional OSPF capabilities are also listed in its Hello packets.
This enables received Hellos to be rejected (i.e., neighbor relationships
will not even start to form) if there is a mismatch in certain crucial OSPF
capabilities. The OSPF optional capabilities currently accepted include
external routing capability and TOS capability.
You need to map the binary bits to the supported options. For example,
“3” indicates both routing capability and TOS capability.
