Lake Shore Model 620/622/623/647 Magnet Power Supply User’s Manual
Remote Operation 4-10
4.3 SUMMARY OF IEEE-488/SERIAL INTERFACE COMMANDS
Below is an alphabetical list of IEEE-488/Serial Interface commands consisting of Operational Commands
(Paragraph 4.3.1), Interface Commands (Paragraph 4.3.2), Ramping Commands (Paragraph 4.3.3), Current
Zero Commands (Paragraph 4.3.4), Current Step Limit Commands (Paragraph 4.3.5), Computed Field
Commands (Paragraph 4.3.6), and Common Commands (Paragraph 4.3.7).
OPERATIONAL COMMANDS
Cmd Function
ERR? Error Status Summary
IMAX Upper Current Limit
IMAX? Upper Current Limit Query
IOUT? Output Current Query
ISET Output Current Setting
ISET? Output Current Setting Query
IV? Output Summary Query
OVP? Overvoltage Protection Query
RES? Resolution
RI?
Remote Inhibit Status Query
VOUT? Output Voltage Query
VSET Compliance Voltage Setting
VSET? Compliance Voltage Setting Query
INTERFACE COMMANDS
Cmd Function
END EOI Status
END? EOI Status Query
MODE Interface Status Mode
MODE? Interface Status Mode Query
TERM Terminator
TERM? Terminator
Query
RAMPING COMMANDS
Cmd Function
RAMP Ramp Segment Parameters
RAMP? Ramp Segment Parameters Query
RMP Ramp Status
RMP? Ramp Status Query
SEG Active Ramp Segment
SEG? Active Ramp Segment Query
CURRENT ZERO COMMANDS
Cmd Function
IMODE? Current Programming Mode Query
VMODE? Voltage Programming Mode Query
ZI Zero Current Value Status
ZI? Zero Current Value Query
ZIS Zero Current Status
ZIS? Zero Current Status Query
CURRENT STEP LIMIT COMMANDS
Cmd Function
ISTP Output Current Step Limit
ISTP? Output Current Step Limit Query
ISTPS Output Current Step Limit Status
ISTPS? Output I Step Limit Status Query
STEP? Output I Step Limit Exceeded Query
STEPR1 Output I Step Limit Exceeded Reset
COMPUTED FIELD COMMANDS
Cmd Function
CFPA Program Computed Field/Amp Constant
CFPA? Computed Field/Amp Constant Query
CFUNI Program Computed Field Display Units
CFUNI? Computed Field Display Units Query
CFPS Set Computed Field Display Status
CFPS? Computed Field Status Query
COMMON COMMANDS
Cmd Function
*CLS Interface Clear
*ESE Std. Event Status Enable Reg
*ESE? Std. Event Status Query
*ESR? Std. Event Status Enable Query
*IDN? Identification Query
*OPC Operation Complete
*OPC? Operation Complete Query
*RST Reset Command
*SRE Service Request
*SRE? Service Request Query
*STB? Status Byte Query
*TST? Self Test Query
*WAI Wait-To-Continue
See Chapter 6 for additional IEEE-488 commands for the following MPS Options:
Model 6226/6476 LHe Level and Gaussmeter Input Card . . . . . . . . . . . . . . . . . . Paragraph 6.2
Model 6228 Persistent Switch Heater Output . . . . . . . . . . . . . . . . . . . . . . . Paragraph 6.3
COMMAND (Shortcut Command): Short command description.
Input: Syntax of user input.
Returned: Informational response to query.
Remarks: Explanation and definition of informational response.
