-43-
Select [2] - [5] to configure other settings as follows:
QoS Other Settings Description
802.1p priority tag 802.1p High Priority Tag Threshold Setting for 802.1p classification
Valid values : 0 - 7
Egress service policy Weighted Round Robin ratio:
(1) 4:1 - 4 high priority packets then 1 low priority packet
(2) 8:1 - 8 high priority packets then 1 low priority packet
(3) 16 :1 - 16 high priority packets then 1 low priority packet
(4) Always high first - Packets in high priority queue are sent first
until the queue is empty
Specific DS(A) Setting Enable - Enable user defined DSCP(A) checking
Disable - User defined DSCP(A) classification is not applied.
Specific DS(A) Value Enter user defined DSCP(A) value for classification.
Specific DS(B) Setting Enable - Enable user defined DSCP(B) checking
Disable - User defined DSCP(B) classification is not applied.
Specific DS(B) Value Enter user defined DSCP(B) value for classification.
Specific IP(A) Setting If a received IP packet ’ s source address or destination address
belongs to the user defined IP network addresses. The packet is
classified as high priority.
Enable - Enable user defined IP(A) network address checking
Disable - IP(A) classification is not applied.
Specific IP(A) Value Set user defined IP(A) address for classification.
Specific IP(A) Mask Value Set user defined IP(A) subnet mask for classification.
IP(A) address and IP(A) subnet mask specify IP(A) user defined
IP network address for IP packet classification.
Specific IP(B) Setting If a received IP packet ’ s source address or destination address
belongs to the user defined IP network addresses. The packet is
classified as high priority.
Enable - Enable user defined IP(B) network address checking
Disable - IP(B) classification is not applied.
Specific IP(B) Value Set user defined IP(B) address for classification.
Specific IP(B) Mask Value Set user defined IP(B) subnet mask for classification.
IP(B) address and IP(B) subnet mask specify IP(B) user defined
IP network address for IP packet classification.
