-36-
4.4 Port Config
Select [3] Port Config to configure port configuration.
Port Config Menu:
[0] Print this menu
[1] Port Status
[2] Port Config
[Q] Back Menu
Please Select(0-3)
Select [1] Port Status to view current port status for all ports as example below:
INET> Port Status:
Port Port Link Auto Speed Duplex Port Auto_No Speed Duplex
+-----+----+------+--------+------+------+--------+--------+-------+-------+
1 TP Down -- -- -- Enable Enable 100 M Full
2 TP Down -- -- -- Enable Enable 100 M Full
3 TP Down -- -- -- Enable Enable 100 M Full
4 TP Down -- -- -- Enable Enable 100 M Full
5 TP Down -- -- -- Enable Enable 100 M Full
6 TP Up Enable 100 M Full Enable Enable 100 M Full
7 TP Down -- -- -- Enable Enable 100 M Full
8 TP Down -- -- -- Enable Enable 100 M Full
+-----+----+------+--------+------+------+--------+--------+-------+-------+
INET>
Status Description
Port The port number
Port Type TP - 10/100TX port (for Port 7 and Port 8 10/100TX is selected)
FX - 100FX is selected (for Port 7 and Port 8 only)
Link Status Port link status
Down - port link down (no status is displayed.)
Up - port link up
Auto Negotia. Auto-negotiation configuration
Enable - auto-negotiation is enabled
Disable - auto-negotiation is disabled (forced mode is used)
Speed Status Port speed status
100M - 100Mbps is used
10M - 10Mbps is used
Duplex Status Port duplex status
Full - full duplex is used
Half - half duplex is used
Port Control Port function configuration
Enable - Port function (Tx/Rx) is enabled
Disable - Port function (Tx/Rx) is disabled
Auto-No Control Port auto-negotiation function
Enable - enable port auto-negotiation
Disable - disable port auto-negotiation (use forced mode)
