-37-
Speed Control Speed configuration when auto-negotiation is disabled
100M - 100Mbps
10M - 10Mbps
Duplex Control Duplex configuration when auto-negotiation is disabled
Full - full duplex
Half - half duplex
Select [2] Port Config to view current port status for all ports as example below:
Port Setting Description
Ports Select port range to be configured.
More than one group can be configured at the same time.
Examples:
123 - Port 1, Port 2, Port 3
1 2 3 - Port 1, Port 2, Port 3
1,2,3 - Port 1, Port 2, Port 3
Port Control Enable / disable port function (Tx/Rx)
Auto Negotiation Enable / disable port auto-negotiation function
Speed Configure speed when port auto-negotiation function is disabled
Duplex Configure duplex when port auto-negotiation function is disabled
4.5 Administrator
Select [4] Administrator to configure advanced settings including VLAN and QoS settings:
Administrator:
[0] Print this menu
[1] VLAN Settings
[2] QoS Settings
[Q] Back Menu
Please Select(0-4)
4.5.1 Administrator -> VLAN Settings
Select [1] VLAN Settings to configure VLAN function related settings:
VLAN Settings Menu:
[0] Print this menu
[1] VLAN Group Information
[2] VLAN Select
[3] VLAN Global Settings
[4] VLAN Group Member Settings
[5] VLAN Group VID Settings
[6] VLAN Per Port Settings
[Q] Back Administrator
Please Select(0-7)
