-12-
10/100TX Twisted Pair Ports
Compliance IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX
Connectors Shielded RJ-45 jacks
Pin assignments Auto MDI/MDI-X detection
Configuration Auto-negotiation
Transmission rate 10Mbps, 100Mbps
Duplex support Full/Half duplex
Flow control IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
Network cable Cat.5 UTP
100FX Fiber Ports
Compliance IEEE 802.3u 100BASE-FX
Configuration Forced 100Mbps, Full duplex
Transmission rate 100Mbps
Far end fault function Capable to receive FEFI (far end fault indication) signal
Capable to send FEFI signal when Rx link failure detected
Flow control IEEE 802.3x pause frame base for full duplex operation
Back pressure for half duplex operation
Network cables MMF 50/125 60/125, SMF 9/125
Eye safety IEC 825 compliant
Optical Specifications Refer to Section 1.8.
Switch Functions
MAC Addresses Table 1K entries
Forwarding & filtering Non-blocking, full wire speed
10Mbps - 14,880 pps at 64-byte packets
100Mbps - 148,800pps at 64-byte packets
Switching technology Store and forward
Maximum packet length 1536 bytes
Broadcast storm 64 consecutive broadcast packets in 800ms
Protection by dropping broadcast storm packets
VLAN function Port-based VLAN & IEEE 802.1Q Tag-based VLAN
QoS function Port-based, 802.1p-based, IP DSCP-based, IP address-based
Port control Port configuration control via software management
LED Indicators
System Power status, Embedded microprocessor operation status
Per 10/100TX port TP port link/activity status, speed status
Per 100FX port FX port link status
