-32-
3.2.5.2 Null VID Replacement (per port setting)
The null VID of a Null VID packet will be replaced with the associated ingress port ’ s PVID. This
setting still works even Egress Tag rule : [PVID insertion for untagged packets only] is selected.
3.2.6 Summary of VLAN Function
Number of VLAN groups : 8 groups at the same time
VLAN ID supported : 1 ~ 4095 (12-bit VID)
VLAN mode options : 802.1Q Tag Aware VLAN, Port-based
Ingress rules :Ingress Member Filtering (global setting)
Unmatched VID Filtering (per port setting)
Egress Tagging rules : Egress Tag Rule (per port setting)
- Tagging with PVID for all packets
- Untagging for all packets
- PVID insertion for untagged packets only
- No tag insertion and tag removal
Null VID Replacement (per port setting)
