-28-
3.1.3.4 IP Network Address Classification
User can configured two IP network address settings, IP(A) and IP(B). If a received IP packet ’ s
source address or destination address belongs to the user defined IP network addresses. The packet is
classified as high priority.
User Defined IP(A) Classification (Global)
Enable - Enable IP(A) checking
Disable - IP(A) classification is not applied.
User Defined IP(B) Classification (Global)
Enable - Enable IP(B) checking
Disable - IP(B) classification is not applied.
3.1.4 Other QoS Settings
• 802.1p High Priority Tag Setting for 802.1p classification
• User Defined DSCP(A) Setting for DSCP classification
• User Defined DSCP(B) Setting for DSCP classification
• User Defined IP(A) Settings for IP network address classification
- IP(A) IP address setting
- IP(A) IP subnet mask setting
• User Defined IP(B) Settings for IP network address classification
- IP(B) IP address setting
- IP(B) IP subnet mask setting
