Industrial 16-Port L2 Fast Ethernet
Switches
KFS-1640
Specifications:
Key Features:

Auto MDI/MDI-X crossover function on the TP copper port

Support IEEE 802.3x flow control for full-duplex operation

Support Back-pressure flow control for half-duplex operation

Transparent forwarding for tagged/untagged, IGMP, RSTP/STP packets with no modification

IEEE 802.3az Energy Efficient Ethernet (EEE)

Wide operating temperature range for temperature critical environment

Support DIN-Rail mounting and panel mounting

Provide two power input types to meet more application needs

DC power input options: +4.5 ~ +50VDC, 110VDC, 90 ~ 240VAC

Accept wide power input voltage range for application flexibility

Industrial-rated Emission and Immunity performance
Standard IEEE 802.3 10BASE-T, IEEE 802.3u 100BASE-TX std.
Network Ports 16 10/100 Fast Ethernet copper ports
Shielded RJ-45 jacks with auto-negotiation, auto-MDI/MDI-X support
Flow control IEEE 802.3x pause packet for full-duplex operation
Back-pressure for half-duplex operation
Cables 10BASE-T: Cat. 3, 4, 5 or higher (100 meters max.)
100BASE-TX: Cat. 5, 5e or higher (100 meters max.)
LEDs Power status
Port link/activity status
Port speed status
Forwarding rate 10Base-T: 10Mbps (Half-duplex) 20Mbps (Full-duplex)
100Base-TX: 100Mbps (Half-duplex) 200Mbps (Full-duplex)
MAC Table 8K entries
Packet Size Up to 2K bytes
Environment Operating Temperature: -20 O C ~ 70 O C (Device)
Storage Temperature: -20 O C ~ 85 O C
Relative Humidity: 10% ~ 90% non-condensing
Dimensions 40 x 106 x 140 mm (WxDxH)
Power Input Voltage KFS-1640-L: +4.5 ~ +50VDC
KFS-1640-H: +110VDC with polarity protection
90 ~ 240VAC
DIN-Rail Mounting
Panel Mounting Bracket
KSD-8PB
