-34-
4.2 IP Menu
Select [1] IP Menu to configure IP protocol related settings for the switch.
IP Menu:
[0] Print this menu
[1] Set IP Address
[2] View IP status
[Q] Back Menu
Please Select(0-3)....
INET>1
Enter Esc to abort..
Please Input IP Address(xxx.xxx.xxx.xxx):192.168.0.232
replacing net[0] IP address192.168.0.232 with 192.168.0.232
Please Input Subnet Mask(xxx.xxx.xxx.xxx):255.255.255.0
replacing subnet mask[0]255.255.255.0 with 255.255.255.0
Please Input Gateway IP(xxx.xxx.xxx.xxx):192.168.0.1
replacing gatewqy IP addr[0] 192.168.0.1 with 192.168.0.1
Do you want to Change IP setting?(Y/N):
IP Settings Description
IP Address : IP address assigned to the switch
Subnet Mask : IP subnet mask of the switch
Gateway IP : IP address of the default gateway of the switch
To view current IP settings of the switch, select [2] View IP status.
IP Menu:
[0] Print this menu
[1] Set IP Address
[2] View IP status
[Q] Back Menu
Please Select(0-3)....
INET> 2
IP Addr: 192.168.0.232 Submask: 255.255.255.0 Gateway: 192.168.0.1
INET>
