Select [6] VLAN Per Port Settings to configure VLAN ID for VLAN groups.
VLAN Per Port Settings:
Port Default Unmatched Egress Null
No. Group VID tag rule VID
+-----+--------+-----------+---------+---------+
1 1 Disabled 4 Disabled
2 1 Disabled 4 Disabled
3 1 Disabled 4 Disabled
4 1 Disabled 4 Disabled
5 1 Disabled 4 Disabled
6 1 Disabled 4 Disabled
7 1 Disabled 4 Disabled
8 1 Disabled 4 Disabled
+-----+--------+-----------+---------+---------+
Enter Esc to abort..
Please Input Ports (1~8):
Per Port Settings Description
Ports Input port list for configuration.
Default Group Index to the default group of the selected ports
Unmatched VID Enable - Drop the tagged packet if the packet’s VID does not match the
ingress port’s PVID
Disable - No Unmatched VID filtering is applied to the port
Egress tag rule Egress Tagging rules are used to make change to the packet before it is
transmitted out from an egress port. Options are:
(1) Tagging with ingress PVID for all packets -
Untagged packet : the packet is inserted with the associated ingress
port’s PVID as tag VID
Tagged packet : the packet’s tag VID is replaced with ingress port’s
PVID as new tag VID
(2) Untagging for all packets -
Untagged packet : the packet is not modified
Tagged packet : the packet’s tag VID is removed and becomes an
untagged packet
Null VID packet : depending on next Null VID Replacement setting
(3) Ingress PVID insertion for untagged packets only -
Untagged packet : the packet is inserted with the associated ingress
port’s PVID as tag VID
Tagged packet : the packet is not modified
(4) No tag insertion and tag removal -
The packet is not modified at all. No tag insertion or tag removal are
performed for all packets.
